NOTES
1. The applicable voltage range is 380V to 415V 50Hz for applications from
380V to 480V and for applications from 60Hz
2. This generator set is of the speed of 1500rpm interchangeable /
1800rpm
3. PT80 is the power for the service of the entire production, where a variable load and unlimited hours of use are applied to the
generator
set
with an average load factor of 80% of the high score over
each 24-hour period. Noting that a 10% surcharge is available for 1 hour in each 12-hour operation4
P88S is a nominal reserve power of the generator set, where a
variable load limited to an annual use of up to 500 hours is applied,
with 300 hours of operation that can be continuous. Nothing that does not overload PT80-PT88S is allowed.
Rating @0.8 P.F |
Prime Rating |
Stand-by rating |
|
|
Voltage*1 |
Frequency*2 |
PT80*3 |
|
PT88S*4 |
400V |
50Hz |
80.0 KVa |
|
88.0 KVa |
Motor technical specifications
model |
Perkins 1104C-44TG24 |
cylinders |
4; vertical in line |
aspiration |
Turbocharger |
combustion |
direct injection |
cooling system |
Cooled water |
movement |
4.4 L |
oil consumption |
0.15% of fuel consumption |
Lubricant capacity |
8.0 L max |
coolant capacity |
13,0L |
Starter |
mechanics |
Emissions regulation |
Non-compliant |
speed |
1500 rpm |
fuel consumption PT80 |
18.7 L/H |
fuel consumption PT88S |
20.5 |
Cooling air flow rate of the radiator |
89.0 m3/ min |
Maximum exhaust gas flow Rate |
13.3 m3/ min |
Alternator technical specifications
Model |
Leroy Somer LSA43.2L8 |
Regulation |
±0.5% |
International protection |
Ip23 |
Insulation class |
H |
Terminals |
12 |
|
|
Frequency |
50 Hz |
Cooling air flow rate |
0. 27 m3 /s |
Transport data
Length |
Width |
Height |
Weight |
1900 mm |
770 mm |
1260 mm |
960 kg |
