Features and benefits
- Maximum power 18.5 Kva
- Rated power 16.25kVA
- Oil alarm
- Electric start
- Equipped with a KM186FAGET engine
- New AVR that reduces current fluctuations
- Analog control panel
- Large tank capacity
Technical Specifications
GENERATOR
Nominal frequency (Hz) 50
Nominal Voltage (V) 230/400
Rated Current (A) 23.5
Nominal power (kVA) 16.25
Maximum Power (kVA) 18.75
Nominal speed (r./min) 3000
Power factor (Ø cos) 0.8
Number of Poles 2
AVR
Table Type Numerical table TTY
Optional Alternator Kt6
Degree of insulation B
Structure Soundproofed
Tank (L) 15
Consumption L/H (load 75, 50, 25%) 1,17 / 0 , 78 / 0,39
Autonomy H (load 75, 50, 25%) 13 / 19 ,2 / 38, 4
Sound Level (dBA/7m) 65
Weight (kg) 177
Dimensions (mm.) (WxWxH) 870x645x710
Start-up system Electric starter
Fuel Diesel
Oil 10W30 / 15W40
Engine Model KM186FAGET
Motor Type 4-stroke, 1 cylinder, water-cooled, diesel
Stroke x Bore 86×72
Displacement (cc) 418
Compression ratio 19:1
Nominal power k W (r/min) 4.2 / 4. 6 3000/3600
