Characteristics and before age
- Maximum power 6.0 Kva
- Rated power 5.5 kV A
- Oil alarm
- Electric start
- Equipped with a KM186FAG engine
- New AVR that reduces current fluctuations
- Analog control panel
- Large tank capacity
- Differential 30 mA
- 1 socket 230 V
- 1 400 V socket
Technical Specifications
GENERATOR
|
Nominal frequency (Hz) |
50 |
|
Nominal Voltage (V) |
230/400 |
|
Rated Current (A) |
7,9 |
|
Nominal power (kVA) |
5,5 |
|
Maximum Power (kVA) |
6 |
|
Nominal speed (r./min) |
3000 |
|
Phi-cos factor (cos ø) |
0,8 |
|
Number of Poles |
2 |
|
AVR |
Yes, it is. |
|
Table Type |
Analog board |
|
TTY |
No |
|
Alternator |
KT5 |
|
Degree of insulation |
B |
|
Structure |
Open |
|
Tank (L) |
13,5 |
Consumption L/H (load 75, 50, 25%) 1,53/1,02/0,51
Autonomy H (load 75, 50, 25%) 9/13,2/26,4
Sound Level (dBA/7m) 79 – 81/
Weight (kg) 100
Dimensions (mm.) (WxWxH) 720x492x650
Start-up system Electric launcher with automatic return
Fuel Diesel
Oil SAE10W30
Differential 30 mA
Engine Model KM186FAG
Motor Type 4 stroke, 1 cylinder, air cooled, diesel
Stroke x Bore 86×72
Displacement (cc) 418
Compression ratio 19:1
Nominal power kW (r/m) 5,7/30
