Features and benefits
- Maximum power 6Kva
- Rated power 5.5kVA
- Oil alarm
- Electric start
- Equipped with a KM186FAG engine
- New AVR that reduces current fluctuations
- Analog control panel
- Large tank capacity
Technical Specifications
GENERATOR
|
Nominal frequency (Hz) |
50 |
|
Nominal Voltage (V) |
400/230 |
|
Rated Current (A) |
7,9 |
|
Nominal power (kVA) |
5,5 |
|
Maximum Power (kVA) |
6 |
|
Nominal speed (r./min) |
3000 |
|
Phi-cos factor (cos ø) |
0.8 |
|
Number of Poles |
3 |
|
AVR |
Yes, it is. |
|
Table Type |
Numerical table |
|
TTY |
Optional |
|
Alternator |
Kt6 |
|
Degree of insulation |
B |
|
Structure |
soundproof |
|
Tank (L) |
15 |
|
Consumption L/H (load 75, 50, 25%) |
1,17 / 0 , 78 / 0,39 |
|
Autonomy H (load 75, 50, 25%) |
13 / 19 ,2 / 38, 4 |
|
Sound Level (dBA/7m) |
65 |
|
Weight (kg) |
148 |
|
Dimensions (mm.) (WxWxH) |
912x532x7 42 |
|
Start-up system |
Electric start |
|
Fuel |
Diesel |
|
Oil |
CD grade or 10w-30, 15w-40 |
|
Differential |
|
|
Engine Model |
KM186FAG |
|
Motor Type |
4-stroke, 1 cylinder, air-cooled, diesel |
|
Stroke x Bore |
86×72 |
|
Displacement (cc) |
418 |
|
Compression ratio |
19:1 |
|
Nominal power kW (r/min) |
5.7 /3000 |
