NOTES
1. The applicable voltage range is 380V to 415V 50Hz for applications from
380V to 480V and for applications from 60Hz
2. This generator set is of the speed of 1500rpm interchangeable /
1800rpm
3. PT200 is the power for the service of the entire production, where a variable load and unlimited hours of use are applied to the
Generator set
With an average load factor of 80% of the high score over
Each 24-hour period. Noting that a 10% surcharge is available for 1 hour in each 12 hours operation.4
P220S is a nominal reserve power of the generator set, where a
Variable load limited to an annual use of up to 500 hours is applied,
With 300 hours of operation that can be continuous. Nothing that does not overload is allowed.
|
Rating @0.8 P.F |
Prime Rating |
Stand-by rating |
||
|
Voltage*1 |
Frequency*2 |
PT200*3 |
|
PT220S*4 |
|
400V |
50Hz |
200.0 KVa |
|
223.0 KVa |
Motor technical specifications
|
model |
Perkins 1306C -R-E87T AG4 |
|
cylinders |
6; vertical in line |
|
aspiration |
Turbo, air to the cooled air charge |
|
combustion |
direct injection |
|
cooling system |
Cooled water |
|
movement |
8.7 L |
|
oil consumption |
0.1% of fuel consumption |
|
Lubrication capacity |
28.3 L |
|
cooling capacity |
24,2L |
|
Starter |
electronic |
|
Emissions regulation |
EU Stage2 & EPA Tier2 |
|
speed |
1500 rpm |
|
fuel consumption PT200 |
45.2 L/ H 51.5 L / H |
|
fuel consumption PT220S |
49.1 L / H 56, 9 L/ H |
|
Cooling air flow rate of the radiator |
439 m3 / min |
|
Maximum exhaust gas flow rate |
36.5 m3 / min |
Alternator technical specifications
|
Model |
Leroy Somer LSA 46.2 M5 |
|
Regulation |
±0.5% |
|
International protection |
Ip23 |
|
Insulation class |
H |
|
Terminals |
12 |
|
Frequency |
50 Hz |
|
Cooling air flow rate |
0.43 m3 /s |
Transport data
|
Length |
Width |
Height |
Weight |
|
4200 mm |
1500 mm |
2100 mm |
2100 kg |
