NOTES

1. The applicable voltage range is 380V to 415V 50Hz for applications from
380V to 480V and for applications from 60Hz
2. This generator set is of the speed of 1500rpm interchangeable /
1800rpm
3. PT200 is the power for the service of the entire production, where a variable load and unlimited hours of use are applied to the
Generator set
With an average load factor of 80% of the high score over
Each 24-hour period. Noting that a 10% surcharge is available for 1 hour in each 12 hours operation.4
P220S is a nominal reserve power of the generator set, where a
Variable load limited to an annual use of up to 500 hours is applied,
With 300 hours of operation that can be continuous. Nothing that does not overload is allowed.

Rating @0.8 P.F

Prime Rating

Stand-by rating

Voltage*1

Frequency*2

PT200*3



PT220S*4

400V

50Hz

200.0 KVa



223.0 KVa

Motor technical specifications

model

Perkins 1306C -R-E87T AG4

cylinders

6; vertical in line

aspiration

Turbo, air to the cooled air charge

combustion

direct injection

cooling system

Cooled water

movement

8.7 L

oil consumption

0.1% of fuel consumption

Lubrication capacity

28.3 L

cooling capacity

24,2L

Starter

electronic

Emissions regulation

EU Stage2 & EPA Tier2

speed

1500 rpm

fuel consumption PT200

45.2 L/ H 51.5 L / H

fuel consumption PT220S

49.1 L / H 56, 9 L/ H

Cooling air flow rate of the radiator

439 m3 / min

Maximum exhaust gas flow rate

36.5 m3 / min


Alternator technical specifications

Model

Leroy Somer LSA 46.2 M5

Regulation

±0.5%

International protection

Ip23

Insulation class

H

Terminals

12

Frequency

50 Hz

Cooling air flow rate

0.43 m3 /s

Transport data

Length

Width

Height

Weight

4200 mm

1500 mm

2100 mm

2100 kg
