NOTES
1. The applicable voltage range is 380V to 415V 50Hz for applications from
380V to 480V and for applications from 60Hz
2. This generator set has a speed of 1500 rpm interchangeable /
1800rpm
3. PT500 is the power for the service of the entire production, where a variable load and unlimited hours of use are applied to the generator
Set with an average load factor of 80% of the high score over each
24-hour period. Noting that a 10% surcharge is available for 1 hour in each 12 hours operation
.4. PT560S is a nominal reserve power of the generator set, where a
variable load limited to an annual use of up to 500 hours is applied,
with 300 hours of operation that can be continuous. Nothing that does not overload is allowed.
|
Rating @0.8 P.F |
Prime Rating |
Stand-by rating |
|
|
Voltage*1 |
Frequency*2 |
PT500*3 |
PT560S*4 |
|
400V |
50Hz |
500.0 KVa |
563.0 KVa |
Motor technical specifications
|
model |
Perkins 2506A-E15T AG2 |
|
cylinders |
6; vertical in line |
|
aspiration |
Turbo, air to the cooled air charge |
|
combustion |
direct injection |
|
cooling system |
Cooled water |
|
movement |
15.2 L |
|
oil consumption |
0.1% of fuel consumption |
| Lubrication capacity |
62L |
|
cooling capacity |
58L |
|
Starter |
electronic |
|
Emissions regulation |
TA Luft compliant |
|
speed |
1500 rpm |
|
fuel consumption PT500 |
106 L/ H |
|
fuel consumption PT560S |
111 L / H 81L/H |
|
Cooling air flow rate of the radiator |
722 m3 / min |
|
Maximum exhaust gas flow rate |
87 m3 /min |
Alternator technical specifications
|
Model |
Leroy Somer LSA 47.2M |
|
Regulation |
±0.5% |
|
International protection |
Ip23 |
|
Insulation class |
H |
|
Terminals |
12 |
|
Frequency |
50 Hz |
|
Cooling air flow rate |
0.9 m 3 /s |
Transport data
|
Length |
Width |
Height |
Weight |
|
3750 mm |
1120 mm |
2150 mm |
3660 kg |
