NOTES
1. The applicable voltage range is 380V to 415V 50Hz for applications from
380V to 480V and for applications from 60Hz
2. This generator set is of the speed of 1500rpm interchangeable /
1800rpm
3. PT95 is the power for the service of the entire production, where a variable load and unlimited hours of use are applied to the
generator set
with an average load factor of 80% of the high score over
each 24-hour period. Noting that a 10% surcharge is available for 1 hour in each 12 hours operation.4
P105S is a nominal reserve power of the generator set, where a variable load limited to an annual use of up to 500 hours is applied,
with 300 hours of operation that can be continuous. Nothing that does not overload is allowed.
|
Rating @0.8 P.F |
Prime Rating |
Stand-by rating |
|
|
|
Voltage*1 |
Frequency*2 |
PT95*3 |
PT105S*4 |
|
|
400V |
50Hz |
95.6 KVa |
|
105.2 KVa |
Motor technical specifications
|
model |
Perkins 1006TG1A |
|
cylinders |
6; vertical in line |
|
aspiration |
Turbocharger |
|
combustion |
direct injection |
|
cooling system |
Cooled water |
|
movement |
5.99 L |
|
oil consumption |
0.5% of fuel consumption |
|
Lubrication capacity |
16,1 L |
|
cooling capacity |
27,7L |
|
Starter |
mechanics |
|
Emissions regulation |
Non-compliant |
|
speed |
1500 rpm |
|
fuel consumption PT95 |
21.8 L/H |
|
fuel consumption PT105S |
24.1 L/H |
|
Cooling air flow rate of the radiator |
115 m3/ min |
|
Maximum exhaust gas flow Rate |
15.5 m3/ min |
Alternator technical specifications
<tdCooling air flow rate
|
Model |
Leroy Somer LSA44.2 VS45 |
|
Regulation |
±0.5% |
|
International protection |
Ip23 |
|
Insulation class |
H |
|
Terminals |
12 |
|
Frequency |
50 Hz |
|
0.37 m3 /s |
Transport data
|
Length |
Width |
Height |
Weight |
|
2300 mm |
770 mm |
1260 mm |
1150 kg |
