NOTES

1. The applicable voltage range is 380V to 415V 50Hz for applications from
380V to 480V and for applications from 60Hz
2. This generator set is of the speed of 1500rpm interchangeable /
1800rpm
3. PT95 is the power for the service of the entire production, where a variable load and unlimited hours of use are applied to the
generator set
with an average load factor of 80% of the high score over
each 24-hour period. Noting that a 10% surcharge is available for 1 hour in each 12 hours operation.4
P105S is a nominal reserve power of the generator set, where a variable load limited to an annual use of up to 500 hours is applied,
with 300 hours of operation that can be continuous. Nothing that does not overload is allowed.

Rating @0.8 P.F

Prime Rating

Stand-by rating



Voltage*1

Frequency*2

PT95*3

PT105S*4

400V

50Hz

95.6 KVa



105.2 KVa

Motor technical specifications

model

Perkins 1006TG1A

cylinders

6; vertical in line

aspiration

Turbocharger

combustion

direct injection

cooling system

Cooled water

movement

5.99 L

oil consumption

0.5% of fuel consumption

Lubrication capacity

16,1 L

cooling capacity

27,7L

Starter

mechanics

Emissions regulation

Non-compliant

speed

1500 rpm

fuel consumption PT95

21.8 L/H

fuel consumption PT105S

24.1 L/H

Cooling air flow rate of the radiator

115 m3/ min

Maximum exhaust gas flow Rate

15.5 m3/ min

Alternator technical specifications

<tdCooling air flow rate

Model

Leroy Somer LSA44.2 VS45

Regulation

±0.5%

International protection

Ip23

Insulation class

H

Terminals

12

Frequency

50 Hz

0.37 m3 /s

Transport data

Length

Width

Height

Weight

2300 mm

770 mm

1260 mm

1150 kg
