Features and benefits

  • Maximum power 3.00 kVa for a wide range of applications
  • Very low noise level of 62-66 db/7m.
  • 8 hours of battery life (75% charge)
  • Inverter technology provides high quality, 100% stable current
  • Design and registered style
  • Electric and manual start for easy use
  • Unique and patented air circulation system

Technical Specifications

GENERATOR

AC frequency Hz                                                50
Nominal ACV voltage                                        230
Nominal Current ACA                                       12.2
Nominal speed (rpm/min)                                   3600
Nominal power (KW)                                       2.8
Maximum power (KW)                                     3.0
DC voltage                                                        12 V – 5 A

Electrical switch                                                 Available for sale Number of phases

Single-phase Engine Model                                KG 205
Type                                                                 1 cylinder, 4 stroke, vertical, air cooled, OHV
Displacement (c.c.)                                            196
Rated power KW /r pm                                     4
Rated rotational speed (rpm)                              3600
Excitation system                                                T.C.I.
Candle                                                                F6RTC/ WR7DC Start-up system

Electric/Manual Consumption L/h (load: 75% / 50% / 25%)              1.65 / 1.10 / 0. 55
Crankcase oil                                                       SAE10W30
Fuel tank capacity (L)                                           13
Fuel                                                                      Unleaded petrol
Autonomy hours (charge: 75%/ 50% / 25%)      8 / 11.8 / 23.6
Noise level (dB) (without load – with maximum load)    62-66

Measurements (L x W x W xH)(mm)                       684 x440 x 505

Weight (Kg)                                                               57
