NOTES
1. The applicable voltage range is 380V to 415V 50Hz for applications from
380V to 480V and for 60Hz applications.
2. This generator set is of the speed of 1500rpm interchangeable /1800rpm
3. PT350 is the power for the service of the entire production, where a variable load and unlimited hours of use are applied to the
Generator set with an average load factor of 80% of the high score over
each 24-hour period. Noting that a 10% surcharge is available for 1 hour in each 12 hours operation.
4. PT410S is a nominal reserve power of the generator set, where a
variable load limited to an annual use of up to 500 hours is applied,
with 300 hours of operation that can be continuous. Nothing that does not overload is allowed.
Rating @0.8 P.F | Prime Rating | Stand-by rating | |
Voltage*1 | Frequency*2 | PT300*3 | PT330S*4 |
400V | 50Hz | 355.7 KVa | 407.9 KVa |
Motor technical specifications
model | Perkins 2206A-E13T AG2 |
cylinders | 6; vertical in line |
aspiration | Turbo, air to the cooled air charge |
combustion | direct injection |
cooling system | Cooled water |
movement | 12.5 L |
oil consumption | 0.1% of fuel consumption |
Lubrication capacity | 40 L |
cooling capacity | 51,4 L |
Starter | electronic |
Emissions regulation | Non-compliant |
speed | 1500 rpm |
fuel consumption PT300 | 71 L/ H 88 L/H |
fuel consumption PT330S | 77 L / H 81L/H |
Cooling air flow rate of the radiator | 563 m / min |
Maximum exhaust gas flow rate | 64.8 m3 |
Alternator technical specifications
Model | Leroy Somer LSA 47.2 VS 2 |
Regulation | ±0.5% |
International protection | Ip23 |
Insulation class | H |
Terminals | 12 |
Frequency | 50 Hz |
Cooling air flow rate | 0.9 m3 /s |
Transport data
Length | Width | Height | Weight |
3400 mm | 1120 mm | 1940 mm | 2950 kg |
