NOTES

1. The applicable voltage range is 380V to 415V 50Hz for applications from
380V to 480V and for applications from 60Hz
2. This generator set is of the speed of 1500rpm interchangeable /
1800rpm
3. PT80 is the power for the service of the entire production, where a variable load and unlimited hours of use are applied to the
generator
set
with an average load factor of 80% of the high score over
each 24-hour period. Noting that a 10% surcharge is available for 1 hour in each 12-hour operation4
P88S is a nominal reserve power of the generator set, where a
variable load limited to an annual use of up to 500 hours is applied,
with 300 hours of operation that can be continuous. Nothing that does not overload PT80-PT88S is allowed.

Rating @0.8 P.F

Prime Rating

Stand-by rating



Voltage*1

Frequency*2

PT80*3



PT88S*4

400V

50Hz

80.0 KVa



88.0 KVa

Motor technical specifications

model

Perkins 1104C-44TG24

cylinders

4; vertical in line

aspiration

Turbocharger

combustion

direct injection

cooling system

Cooled water

movement

4.4 L

oil consumption

0.15% of fuel consumption

Lubricant capacity

8.0 L max

coolant capacity

13,0L

Starter

mechanics

Emissions regulation

Non-compliant

speed

1500 rpm

fuel consumption PT80

18.7 L/H

fuel consumption PT88S

20.5

Cooling air flow rate of the radiator

89.0 m3/ min

Maximum exhaust gas flow Rate

13.3 m3/ min


Alternator technical specifications

Model

Leroy Somer LSA43.2L8

Regulation

±0.5%

International protection

Ip23

Insulation class

H

Terminals

12





Frequency

50 Hz

Cooling air flow rate

0. 27 m3 /s

Transport data

Length

Width

Height

Weight

1900 mm

770 mm

1260 mm

960 kg
