NOTES
1. The applicable voltage range is 380V to 415V 50Hz for applications from
380V to 480V and for applications from 60Hz
2 This generator set is of the speed of 1500rpms interchangeable /1800rpm
3. PT230 is the power for the service of the entire production, where a variable load and unlimited hours of use are applied to the
Generator set
With an average load factor of 80% of the high score over
Each 24-hour period. Noting that a 10% surcharge is available for 1 hour in each 12 hours operation.
4. P250S is a nominal reserve power of the generator set, where a variable load limited to annual use up to 500 hours is applied, with 300 hours of operation that can be continuous. Nothing that does not overload is allowed.
Rating @0.8P.F |
Prime Rating |
Stand-by rating |
|
|
Voltage*1 |
Frequency*2 |
PT230*3 |
|
PT250S*4 |
400V |
50Hz |
228.7 KVa |
|
249.5 KVa |
model |
Perkins 1306C -R-E87T AG4 |
cylinders |
6; vertical in line |
aspiration |
Turbo, air to the cooled air charge |
combustion |
direct injection |
cooling system |
Cooled water |
movement |
8.7L |
oil consumption |
0.1% of fuel consumption |
Lubrication capacity |
28.3L |
|
|
cooling capacity |
24,2L |
Starter |
electronic |
Emissions regulation |
EU Stage2 & EPA Tier2 |
speed |
1500 rpm |
fuel consumption PT230 |
48.5 L/ H |
fuel consumption PT250S |
53.0 L / H |
Cooling air flow rate of the radiator |
440 m3 / min |
|
|
Maximum exhaust gas flow rate |
0.3 kg / min |
Motor technical specifications
Alternator technical specifications
Model |
Leroy Somer LSA 47.2 M |
Regulation |
±0.5% |
|
|
International protection |
Ip23 |
|
|
Insulation class |
H |
Terminals |
12 |
Frequency |
50 Hz |
Cooling air flow rate |
0.43 m3 /s |
Transport data
Length |
Width |
Height |
Weight |
4200 mm |
1500 mm |
2100 mm |
3660 kg |
