Features and benefits

  • Maximum power 6Kva
  • Rated power 5.5kVA
  • Oil alarm
  • Electric start
  • Equipped with a KM186FAG engine
  • New AVR that reduces current fluctuations
  • Analog control panel
  • Large tank capacity

Technical Specifications

GENERATOR

Nominal frequency (Hz)

50

Nominal Voltage (V)

400/230

Rated Current (A)

7,9

Nominal power (kVA)

5,5

Maximum Power (kVA)

6

Nominal speed (r./min)

3000

Phi-cos factor (cos ø)

0.8

Number of Poles

3

AVR

Yes, it is.

Table Type

Numerical table

TTY

Optional

Alternator

Kt6

Degree of insulation

B

Structure

soundproof

Tank (L)

15

Consumption L/H (load 75, 50, 25%)

1,17 / 0 , 78 / 0,39

Autonomy H (load 75, 50, 25%)

13 / 19 ,2 / 38, 4

Sound Level (dBA/7m)

65

Weight (kg)

148

Dimensions (mm.) (WxWxH)

912x532x7 42

Start-up system

Electric start

Fuel

Diesel

Oil

CD grade or 10w-30, 15w-40

Differential



Engine Model

KM186FAG

Motor Type

4-stroke, 1 cylinder, air-cooled, diesel

Stroke x Bore

86×72

Displacement (cc)

418

Compression ratio

19:1

Nominal power kW (r/min)

5.7 /3000
