NOTES
1. The applicable voltage range is 380V to 415V 50Hz for applications from
380V to 480V and for applications from 60Hz
2 This generator set is of the speed of 1500rpm interchangeable /
1800rpm
3. PT30 is the power for the service of the entire production, where a variable load and unlimited hours of use are applied to the
generator set
with an average load factor of 80% of the high score over
each 24-hour period. Noting that a 10% surcharge is available for
1 hour in each 12-hour operation4
PT33S is a nominal reserve power of the generator set, where a variable load limited to an annual use of up to 500 hours is applied,
with 300 hours of operation that can be continuous. Nothing that does not
overload is allowed.
|
Rating @0.8 P.F |
Prime Rating |
Stand-by rating |
|
|
Voltage*1 |
Frequency*2 |
PT30*3 |
PT33S*4 |
|
400V |
50Hz |
30.7 KVa |
32.86 KVa |
Motor technical specifications
|
model |
Perkins 1103A-33G |
|
cylinders |
3; vertical in line |
|
aspiration |
atmospheric |
|
combustion |
indirect injection |
|
cooling system |
Cooled water |
|
movement |
3.30 L |
|
oil consumption |
0.15% of fuel consumption |
|
Lubricant capacity |
8,30 L |
|
coolant capacity |
10,20L |
|
Starter |
mechanics |
|
Emissions regulation |
TA-Luf t(1986) |
|
speed |
1500 rpm 1800 rpm 1800 rpm |
|
fuel consumption PT30 |
7.1 L/H |
|
fuel consumption PT33S |
7.9 L/H 9.5 L/H |
|
Cooling air flow rate of the radiator |
53.0 m3/ min |
|
Maximum exhaust gas flow Rate |
5.7 m3/ min |
Alternator technical specifications
|
Model |
Leroy Somer LSA42.3VS3 |
|
Regulation |
± 1% |
|
International protection |
Ip23 |
|
Insulation class |
H |
|
Terminals |
12 |
|
Frequency |
50 Hz |
|
Cooling air flow rate |
0. 10 m3 /s |
Transport data
|
Length |
Width |
Height |
Weight |
|
2270 mm |
1100 mm |
1250 mm |
760 kg |
