Features and benefits
- Maximum power 15.0 Kva
- Rated power 13.5 kVa
- Digital control panel
- Soundproof (75db)
- Equipped with a KM376AG 3-cylinder, water-cooled engine
- New AVR that reduces current fluctuations
- ATS connection
- 4 doors with 180º opening for easy maintenance
- 2 x 230 V sockets
Technical Specifications
GENERATOR
| Nominal frequency (Hz) | 50 |
| Nominal Voltage (V) | 230/400 |
| Rated Current (A) | 19.5 |
| Nominal power (kVA) | 13.5 |
| Maximum Power (kVA) | 15 |
| Nominal speed (r./min) | 3000 |
| Power factor (Ø cos) | 0.8 |
| Number of Poles | 2 |
| AVR | Yes, it is. |
| Table Type | Digital Table |
| ATS connection | Optional |
| Alternator | KTS16 |
| Degree of insulation | F |
| Structure | Soundproofed |
| Tank (L) | 38 |
| Consumption L/H (load 75, 50, 25%) | 3,41/2,27/1,14 |
| Autonomy H (load 75, 50, 25%) | 1 1/16,7/33,4 |
| Sound Level (dBA/7m) | 72-75 |
| Weight (kg) | 420 |
| Dimensions (mm.) (WxWxH) | 1540x845x925x925 |
| Start-up system | Electric 12V |
| Fuel | Diesel |
| Oil | 15W30 / 15W40 |
| Engine Model | KM376AG |
| Motor Type | 4 stroke, 3 cylinders, ref. by water, diesel |
| Stroke x Bore | 3-76×77 |
| Displacement (cc) | 1048 |
| Compression ratio | 21,5:1 |
| Nominal power kW (r/min) | 15,3/3000 17,5/3600 |
