The Makita 196008-1 drill chuck is a durable gear rim drill chuck designed for use with tools featuring a 1/2″-20 UNF spindle thread. With a maximum clamping capacity of 13 mm and a minimum of 1 mm, it provides precise and secure bit retention for a wide range of drilling applications.
Made of robust steel, the chuck is engineered for stability and long service life, particularly in heavy-duty construction tasks. The gear rim design allows for strong clamping force, making it especially effective when using larger drill bits. The chuck comes with a key for convenient tightening and loosening, ensuring reliable performance.
This drill chuck can also be used with SDS-plus machines when paired with an SDS-plus adapter, making it versatile for use with drilling machines, cordless screwdrivers, and hammer drills.
TECHNICAL DETAILS:
| Specification | Details |
| Brand | Makita |
| Model | 196008-1 |
| Product Type | Keyed Drill Chuck with Key |
| Spindle Thread | 1/2″-20 UNF |
| Diameter (Clamping Capacity) | 13 mm (max), 1 mm (min) |
| Span Width | 1.5 mm – 13 mm |
| Drill Chuck Type | Keyed (gear rim) |
| Drill Chuck Connection | 1/2″-20 UNF |
| Material | Robust steel |
| Included | Drill chuck + key |
| Application | For use with drilling machines, cordless screwdrivers, and hammer drills (with SDS-plus adapter if required) |
