The Yato YT-81481 Power Inverter allows electrical equipment requiring mains electricity to be powered directly from a 12V car battery or 12V DC installation. Thanks to its small size, lightweight design (1.28kg), and high efficiency (>85%), it is ideal for use in areas without access to the mains.
Key features include:
- Pure sine wave output for safe operation of sensitive electronics.
- 300W continuous power, 600W peak power.
- Wide input voltage range (11–15V DC).
- USB outputs:
- Type A: 5V, max 2.1A
- Type C: 5V/9V/12V, max 3.1A/2A/1.5A
- Multifunctional protections: short-circuit, overheating, overload, overvoltage, undervoltage.
- Low battery alarm at 10.5V DC.
- Automatic shutdown at 9.5V DC or overload conditions.
- Compatible with STD, GEL, AGM, and LiFePO4 batteries.
- Fuse protection (40A ×1).
- Operating temperature range: –15°C to +25°C.
- Indicators for power supply and faults.
Compact and reliable, this inverter is perfect for powering laptops, routers, small appliances, and other devices when traveling or camping.
TECHNICAL DETAILS:
| Specification | Details |
| Model | YT-81481 |
| Brand | Yato |
| Series | GRF |
| Rated Power | 300W |
| Peak Power | 600W |
| Input Voltage | 12V DC |
| Operating Input Voltage | 11–15V DC |
| Output Voltage | 230V AC |
| Output Operating Voltage | 230V ± 10% |
| Output Frequency | 50Hz |
| Efficiency | ≥85% |
| Output Waveform | Pure sine wave |
| USB Outputs | Type A: 5V/2.1A; Type C: 5V/3.1A, 9V/2A, 12V/1.5A |
| No-load Current Intake | |
| Low Battery Alarm Voltage | 10.5V ± 0.3V |
| Inverter Switch-off Voltage | 9.5V ± 0.3V |
| Input Overload Voltage | 16V ± 0.3V |
| Power Overload Protection | 350–450W |
| Fuse | 40A ×1 |
| Protection Grade | IPX0 |
| Insulation Class | I |
| Operating Temperature | –15°C to +25°C |
| Weight | 1.28kg |
| Application | Powering 230V AC devices from 12V DC batteries/car installations |
| Responsible Entity (EU) | TOYA S.A. |
