Long Description:
The FelicitySolar FL-IVPS1512 Li is a powerful low frequency inverter charger designed for durability and reliable off-grid or backup power. It delivers 1200W continuous output with a peak surge capacity of 3KVA, making it suitable for homes, small offices, and isolated sites.
Key features include:
- Lithium battery wake-up function for seamless operation with modern batteries.
- Bypass charging function for convenient AC power supply.
- Wide input voltage range (90–280V AC) for reliable performance.
- Selectable grid or battery priority modes.
- Three-stage intelligent charging system to maximize battery life.
- Overload, short circuit, and overcharge protection for enhanced safety.
Compact and robust, this inverter charger combines intelligent power management with eco-friendly design, ensuring efficient and safe energy conversion.
TECHNICAL DETAILS:
| Specification | Details |
| Model | FL-IVPS1512 Li |
| Rated Output Power (VA) | 1500VA |
| Rated Output Power (W) | 1200W |
| Nominal DC Input | 12V |
| Nominal AC Input Voltage | 220V AC |
| Max. AC Input Voltage | 280V RMS |
| Nominal Input Frequency | 50Hz / 60Hz |
| Peak Surge Capacity | 3000VA |
| Pass Through Without Battery | No |
| Max. AC Input Current | 10A |
| Max. Bypass Overload Current | 10A |
| Max. Charging Current | 18A |
| Battery Initial Voltage | 12V |
| Circuit Breaker | AC 10A |
| Output Waveform | Pure sine wave |
| Protections | Overload, short circuit, overcharge |
| Brand | FelicitySolar |
