The COB-61A Push-Button Switch is part of CNC Electric’s COB Series, designed for remote control of cranes, hoists, and industrial machinery. It features two mechanical buttons (typically UP/DOWN) with built-in interlock to prevent simultaneous activation.
Rated for circuits up to AC380V or DC250V at 50/60Hz, it offers overload protection, short-circuit protection, and control functionality. The IP65-rated enclosure made of shockproof ABS resin ensures durability in snowy, dusty, and humid conditions. Terminals are M4 screw type, and the unit supports AC220V and AC440V operation.
TECHNICAL DETAILS:
| Specification | Details |
| Model | COB-61A |
| Series | COB Push-Button Switch |
| Number of Buttons | 2 (UP/DOWN) |
| Rated Voltage | AC ≤ 380V / DC ≤ 250V |
| Rated Frequency | 50/60Hz |
| Rated Current | AC15: 2.5A @ 380V, 4.5A @ 220V |
| DC Load Capacity | DC13: 0.3A @ 220V, 0.6A @ 110V |
| Insulation Voltage | AC500V |
| Terminal Type | M4 Screw |
| Protection Grade | IP65 (JIS C 0920) |
| Housing Material | Shockproof ABS Resin |
| Operating Temperature | -15°C to +40°C |
| Relative Humidity | 45% to 85% |
| Dimensions (H×W×D) | 224 × 68 × 50 mm |
| Cable Diameter Range | 11.4 to 12.6 mm |
| Mounting Type | Vertical, cable entry at top |
| Features | Mechanical interlock, built-in button packing |
