The CJX2-80008 AC Contactor from Yato is engineered for controlling AC motors and other electrical loads in circuits up to 380V. With a rated current of 80A, it supports frequent switching, making and breaking operations in demanding industrial environments.
This model features a 4-pole configuration with 2NO + 2NC contacts, suitable for complex control circuits. It complies with IEC 60947-4-1 standards and can be integrated with auxiliary contact blocks, timers, and thermal relays to form reversible contactors, star-delta starters, or electromagnetic starters.
The contactor offers high durability, reliable performance, and compatibility with coil voltages ranging from 24V to 600V, including 380V for this variant.
TECHNICAL DETAILS:
| Specification | Value |
| Product Name | CJX2-80008 |
| Rated Current | 80A |
| Rated Voltage | 380V AC |
| Number of Poles | 4P |
| Contact Configuration | 2NO + 2NC |
| Coil Voltage | 380V |
| Frequency | 50Hz / 60Hz |
| Standard | IEC 60947-4-1 |
| Rated Insulation Voltage (Ui) | 690V |
| Rated Thermal Current (Ith) | 125A |
| Max Motor Power (AC-3, 400V) | 37–45 kW |
| Electrical Life | Up to 1 million operations |
| Mechanical Life | Up to 10 million operations |
| Control Circuit Voltage Range | 85%–110% Us |
| Drop-out Voltage Range | 20%–75% Us |
| Matching Thermal Relay | JR28-93 |
| Matching Fuse | RT16-80 |
| Application | Motor control, automation |
